Electrical Characteristics (Ta=25℃)
| LED forward voltage Minimum | 1.5V |
|---|
| LED forward voltage Typical | 1.65V |
|---|
| LED forward voltage Maximum | 1.8V |
|---|
| Reverse current | 10μA |
|---|
| Capacitance between terminals | 40pF |
|---|
| Trigger LED forward current Typical | 0.6mA |
|---|
| Trigger LED forward current Maximum | 3mA |
|---|
| Release LED forward current Minimum | 0.1mA |
|---|
| Maximum resistance with output ON Typical | 0.14Ω |
|---|
| Maximum resistance with output ON Maximum | 0.3Ω |
|---|
| Current leakage when the relay is open Maximum | 1000nA |
|---|
| Capacitance between terminals Typical | 95pF |
|---|
| Capacitance between I/O terminals | 0.4pF |
|---|
| Insulation resistance between I/O terminals Typical | 10^8Ω |
|---|
| Turn-ON time Typical | 0.13ms |
|---|
| Turn-ON time Maximum | 0.5ms |
|---|
| Turn-OFF time Typical | 0.04ms |
|---|
| Turn-OFF time Maximum | 0.2ms |
|---|
*This page contains information excerpted from the product catalog. For other product information, please see the data sheet and other various data.
